Top Entry-Single Bag Filter Housing

Short Description:

The top-entry bag filter is a premium single-bag filtration unit engineered for maximum efficiency. Its advanced top-inlet design minimizes sealing points and eliminates dead zones for residue accumulation, ensuring exceptional filtration performance, effortless operation, and easy cleaning.

Built for durability, the heavy-duty filter housing features precision-cast components and seamless stainless steel tubing. With only two weld seams across the entire body, it delivers superior structural strength, high pressure resistance, and a sleek, streamlined profile.

Get a Quote

Product Detail

Product Tags

Working Principle

The top-entry bag filter operates on an inside-out filtration principle driven by system pressure. Unfiltered liquid enters through the top inlet and flows smoothly into the filter bag, where solid contaminants are securely captured inside while clean fluid passes through to the bottom outlet. This top-inlet design ensures uniform flow distribution and eliminates dead zones, making filter bag replacement and system cleaning exceptionally quick and efficient.

Complete Filtration System


Key Features

①Top-Inlet Elbow: Minimizes residue and ensures easy cleaning.

②Precision-Cast Lid: One-piece stainless steel filter cover for maximum durability.

③Zero-Bypass Seal: Specialized design to eliminate leakage.

④Two-Weld-Seams: Streamlined filter housing with enhanced structural strength.

⑤Adjustable Legs: Height-adjustable support legs for flexible installation.

⑥Material Options: Carbon steel, 304 stainless steel, and 316 stainless steel.

⑦Design Pressure: Wide operating range from 6 bar to 21 bar.

⑧Custom O-Rings: Tailored to specific chemical compatibility and temperature.

Applications

Water Treatment: Used for raw water pre-treatment, circulating water systems, and process water filtration
Chemical Industry: Filters chemical liquids, solvents, and particulate impurities in various process fluids
Food & Beverage: Used for purification of liquid raw materials, additives, and process water
Pharmaceutical Industry: Applied in liquid clarification and pre-filtration during pharmaceutical processes
Petrochemical Industry: Used for impurity control in oils, chemical additives, and process fluids
Coatings & Paints: Removes particles to ensure product consistency and quality
Electronics Industry: Used for pre-filtration of ultra-pure water and process liquids
